| Resolution |
8 dots/mm (203 DPI) |
| Printing method |
Thermal Transfer & Direct Thermal |
| Max. print speed |
127 mm (5”)/second |
| Max. print width |
108 mm (4.25“) |
| Max. print length |
2,286 mm (90“) |
| Enclosure |
ABS plastic |
| Physical dimension |
232 mm (W) x 156 mm (H) x 288 mm (D)
9.13“ (W) x 6.14“ (H) x 11.34“ (D) |
| Weight |
2.5 kg (5.51 lbs) |
| Label roll capacity |
110 mm (4.33“) OD |
| Ribbon |
300 m long, max. OD 67 mm, 1“ core (ink coated outside) |
| Ribbon width |
40 mm ~ 110 mm (1.6” ~ 4.3”) |
| Processor |
32-bit RISC CPU |
| Memory |
4 MB Flash memory
8 MB SDRAM
SD card reader for Flash memory expansion, up to 4 GB (user option) |
| Interface |
USB 2.0
RS-232
Centronics (factory option)
Bluethooth (user option)
External 802.11 b/g/n wireless (user option) |
| Power |
External universal switching power supply
Input: AC 100-240V, 2.5A, 50-60Hz
Output: DC 24V, 2.5A, 60W |
| Operation switch, button, LED |
1 power switch, 1 feed button & 3 LED (Power, Error, On-line) |
| Sensors |
Gap transmissive sensor
Black mark reflective sensor
Ribbon end sensor |
| Internal fonts |
8 alpha-numeric bitmap fonts
Monotype Image® true type font engine with one CG Triumvirate Bold Condensed scalable font |
| Bar code |
1D bar code : Code 39, Code 93, Code 128UCC, Code 128 subset A, B, C, Codabar, Interleave 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2 (5) digits add-on, MSI, PLESSEY, POSTNET,RSS-Stacked, GS1 DataBar, Code 11
2D bar code : PDF-417, Maxicode, DataMatrix, QR Code, Aztec |
| Font and barcode rotation |
0, 90, 180, 270 degree |
| Printer language |
TSPL-EZTM (Compatible to EPL, ZPL, ZPL II) |
| Media type |
Continuous, die-cut, black mark, fan-fold, notched (outside wound) |
| Media width |
25.4 ~ 112 mm (1.0” ~ 4.4”) |
| Media thickness |
0.06 ~ 0.25 mm (2.36 ~ 9.84 mil) |
| Media core diameter |
25.4 ~ 76.2 mm (1” ~ 3”) |
| Label length |
10 ~ 2,286 mm (0.39“ ~ 90“) |
| Environment condition |
Operation: 5 ~ 40°C, 25 ~ 85% non-condensing
Storage: -40 ~ 60°C, 10~ 90% non-condensing |
| Safety regulation |
FCC Class A, CE Class A, C-Tick Class A, TÜV/Safety, CCC |
| Environmental concern |
Comply with RoHS, WEEE |
| Accessories |
Windows labeling software CD disk
Quick start guide
Power cord
External universal switching power supply
Label spindle, fixing tab x 2
Ribbon spindle x 2
Ribbon paper core |
| Limited warranty |
Printer: 2 years
Print head: 25 km (1 million inches) or 12 months which comes first
Platen: 50 km (2 million inches) or 12 months which comes first |
| Factory options |
Centronics parallel & RS-232 serial interfaces |
| User options |
Bluetooth module (serial interface)
802.11 b/g/n wireless module (serial interface)
External roll mount, media OD. 214 mm (8.4”) on a 1” or 3” core
SD Flash memory card reader
3” core label spindle
KP-200 Plus keyboard display unit
KU-007 Plus programmable smart keyboard |
