Printronix

Printronix T8000 Barcode Printer

The T6000e is one of the most versatile printers on the market with the ability to print 10,000 labels a day at
record setting speeds, offers high quality 600 dpi printing, and includes a full suite of communication options.
A barcode verification option is also available.
The T6000e RFID print/encodes on both standard and on-metal RFID labels and comes with an automated
strikeout feature for tags that fail to encode properly.

Download PDF
Specification
Product Benefits
  • High performance ARM Cortex-A9
  • Available in 203 DPI and 300 DPI
  • Die-cast aluminum frame w/metal door
  • Dual motor ribbon drive system
  • Transfer and direct printing
  • 512MB RAM / 128MB Flash Memory
  • 4”, 6”, and 8” model configurations
  • 4-32 GB SD memory card capability
  • Premium Asian and Andale font support
  • ENERGY STAR Certified
  • State-of-the-art WiFi connectivity
Printer Specifications
Max Print Speed (4”/6”/8”) 14/12/10 IPS @ 203 DPI; 12/10/8 IPS @ 300 DPI
Print Method Transfer and Direct
Resolution 203 DPI or 300 DPI
Resolution (6”) 203/ 300 DPI
Max. Print Width 4.1” (104mm) / 6.6” (168mm) / 8.5” (216mm)
Printer Memory 512MB RAM / 128MB Flash
Media Specifications
Media Type Roll or Fan-Fold Labels, Tags, Paper, Film, Tickets
Min. Media Width(4”/6”/8”) 1” (25.4mm) / 2” (50.8mm) / 3” (76.2mm)
Max. Media Width 4.5” (114.3mm) / 6.8” (172.7mm) / 8.75” (222.2mm)
Min. Media Length 0.25” / 1.0” (Continuous/Tear-Off) / 0.5” (Peel-Off)
Max. Media Length Up to 99”
Media Thickness 2.5mm (0.0025”) to 10mm (0.010”)
Media Roll Core Diameter 1.5” (37.5mm) to 3.0” (76mm)
Max. Media Roll Diameter 8.0” (203.2mm)
Media Sensing Gap, Mark, Advanced Gap, Advanced Notch
Ribbon Specification
Ribbon Type Wax, Wax/Resin, Resin
Min. Ribbon Width(4”/6”/8”) 1” (25.4mm)/2” (50.8mm)/ 3” (76.2mm)
Max. Ribbon Width(4”/6”/8”) 4.5” (114.3mm)/6.8” (172.7mm)/ 8.75” (222.2mm)
Max. Ribbon Length 625Meters
Physical Characteristics
Width(4”/6”/8”) 11.7” (297.2mm) / 13.4” (340.4mm) / 15.4” (391.2mm)
Height(4”/6”/8”) 13” (330.2mm) / 13” (330.2mm) / 13” (330.2mm)
Depth(4”/6”/8”) 20.5” (520.7mm) / 20.5” (520.7mm) / 20.5” (520.7mm)
Printer Weight(4”/6”/8”) 37 lbs. (16.7Kg.) / 40 lbs. (18.1 Kg.) / 43 lbs. (19.5Kg.)
Shipping Weight(4”/6”/8”) 46 lbs. (20.8Kg.) / 49 lbs. (22.2 Kg.) / 52 lbs. (23.6Kg.)
Printer Language
  • IGP Languages : PGL/VGL/ZGL/TGL/IGL/STGL/DGL/IEGL/MGL/EGL
  • Line Printer Plus Languages : P-Series + XQ, Proprinter, Serial Matrix, Epson
  • Job Control Languages : PJL, XML, and PTX-SETUP
  • Optional Languages : IPDS, PDF Level 1.7, Postscript Level 3, TN5250/TN3270
Communication and Connectivity/Interface
Standard Interface I/O Serial RS232, USB, and Ethernet 10/100Base T
Optional Interface I/O Parallel, WiFi (802.11a/b/g/n), GPIO
WiFi Security Protocol WEP 40/128bit, WPA Personal (PSK), WPA2 Personal
(PSK) Enterprise (AES CCMP)EAP-TLS, EAP-TTLs, PEAPv0/ MS-CHAPv2, PEAPv1, EAP-MDS
Media Handling
  • Standard : Continuous, Tear-Off Strip, Tear-Off
  • Options : Peel-Off, Cut, and Rewind
Operating Environment
Operating Temperature Direct Thermal w/o accessories: 23 to 104F (-5 to 40C)
Thermal Transfer: 40 to 104F (5 to 40C)
Operating Humidity 20-85% Non-Condensing
Storage Temperature 23 to 140 F (-5 to 60 C)
Storage Humidity 5 to 85% Non-Condensing
Regulatory Compliance
Emissions FCC, CE, CCC
Safety cTUVus, CE, EAC, SABS, RCM, CCC, KC, S-MARK, NOM
Environmental RoHS, WEEE, Energy Star
Bar Code Symbologies
1D Barcodes BC-412, Code 11, Code 39, Code 35, Code 93, Codabar, Code128 Subsets A/B/C, Industrial 2 of 5, Interleave 2 of 5, German I-2/5, EAN-8, EAN-13, UCC/ EAN-128, UPC-A, UPC-E, UPCSHIP, UPS 11, MSI, Matrix 2 of 5, PLESSEY, POSTNET, 4-state PostBar, Australian 4-state, FIM, ITF14, TELEPEN, PLANET, USPS Intelligent Mail, LOGMARS
2D Barcodes PDF-417, MicroPDF-417, Maxicode, DataMatrix, QR Codes, Aztec, GS1 Databar (RSS-14)
Font, Graphic Support
Graphic Formats PCX, TIFF, BMP, PNG
Font Technologies Intellifont, TrueType, Unicode
Standard Fonts OCRA, OCRB, Courier, Letter Gothic, CG Times, CG
Triumvirate/Bold/Condensed
Asian Fonts (Optional SD card) Simplified Chinese, Japanese, Korean, Thai
