Honeywell

Honeywell ScanPal™ EDA52/HC (WWAN/WLAN)

The ScanPal™ EDA52 is a cutting-edge mobile computer by Honeywell, boasting a Qualcomm Snapdragon octa-core 2.0GHz processor and robust wireless connectivity including NFC, Wi-Fi 5, Bluetooth 5.1, and 4GLTE. Its 5.5-inch Gorilla Glass touch screen and ergonomic design enhance user comfort and experience. Equipped with a 13-megapixel rear camera for high-resolution image capture and a 5-megapixel front camera for video communication, it also features the Honeywell S0703 scan engine for fast barcode reading, even of damaged codes.

With rugged housing and IP67 sealing, it withstands rough usage and harsh environments. The 4500mAh battery ensures prolonged use and supports quick charging. It supports one nano SIM and one e-SIM simultaneously, facilitating easy management of mobile network subscriptions. Built on Android11 with upgradeability to Android 13, it’s validated under AER for long-term support and easy deployment in businesses.

Add to Enquiry
Download PDF
Specification
MECHANICAL
Dimensions (L x W x H): 159mm x 75 mm x 14.4 mm (6.26 in x 2.95 in x 0.57 in)
Weight: 258g
Display Size:  Gorilla Glass 5, 5.5 inches
Resolution:  1440 x 720 High Definition
Backlight: LED
Touchscreen:  Multi-touch capacitive (CTP), GFF
Hard Keys:  5 side keys for volume up/down, right and left scan keys and power on/off
SYSTEM ARCHITECTURE
Processor: Qualcomm Snapdragon SM6115, Quad high-performance Kryo cores 2.0 GHz +Quad low-power Kryo cores 1.8 GHz
Memory: 3 GB RAM/32 GB Flash; 4 GB RAM/64 GB Flash; 6 GB RAM/128 GB Flash
Operating System: Android 11, and upgradeable to Android 13
Storage Expansion: Multiple 1.3m (4.3ft) per MIL-STD 810G drops to concrete at room temperature Multiple 1.5m (5ft) per MIL-STD 810G drops with rubber boot concrete at room temperature
Rear Camera: 13-megapixel color camera
Front Camera: 5-megapixel color camera
PC Interface: USB 2.0 with Type-C interface
Interface Ports: 2 pin bottom connection / 6 pin bottom connection
Battery: Li-Ion, 3.8 V, 4,500 mAh, removable
Real-Time Clock (RTC): 10 min backup via super-cap
Charging Time: less than 3.5 hours
Scan Engine: Honeywell S0703 Slim Imager (1D/2D barcode symbologies); Non-imager version (optional)
ENVIRONMENTAL
Operating Temperature:  -20°C to +50°C (-4°F to +122°F)
Storage Temperature:  -30°C to +70°C (-22°F to 158°F)
Humidity:  5% to 90% (non-condensing)
Drop:

Multiple 1.3m (4.3ft) per MIL-STD 810G drops to concrete at room temperature

Multiple 1.5m (5ft) per MIL-STD 810G drops with rubber boot concrete at room temperature
Tumble: 550 times at 0.5 m (1.64 ft)
Environmental Sealing: IP67
Electrostatic Discharge (ESD): ±8 kV direct; ±15 kV air
CONNECTIVITY
WLAN (Wi-Fi Alliance certified) IEEE 802.11 a/b/g/n/ac
Additional WLAN Features: 802.11 d/e/h/i/k/ r/u/w /v , 1X1 MU-MIMO
WLAN Security: OPEN, WEP, WPA/WPA2
(Personal and Enterprise WPA2), WPA3
(OWE, SAE, Enterprise)
WLAN Supported EAP: TLS, PEAP, TTLS, PWD, LEAP
Bluetooth: Bluetooth Class 5.1
WWAN Radio:

GSM/EDGE: Bands 2, 3, 5, 8

UMTS/HSPA+: Bands 1, 2, 4, 5, 6, 8, 9, 19

FDD-LTE: Bands 1, 2, 3, 4, 5, 7, 8, 9, 12,13,17,19,20,25,26,28,30,66

TDD-LTE: Bands 38, 39, 40, 41
NFC: Integrated Near Field Communication
GPS (WWAN only) Supported Protocols: Simultaneous receiver support for GPS, GLONASS, and BeiDou
ACCESSORIES
Single Charging Home Base: Charges one terminal and one replaceable battery simultaneously
Backwards Adaptor Cup: Be compatible with EDA50/51 single charging dock
Standard Battery Pack
Quad Bay Battery Charger
RFID Bracket
Scan Handle
Rubber Boot
Wrist Strap
Hand Strap
Screen Film
Single Charging Dock: Charges one terminal
Quad Bay Charging Base: Charges four terminals simultaneously
