Cipherlab

Cipherlab RS51 Android Mobile Computer

With the development of E-commerce, delivery speed is in demand for industries such as transportation and logistics and direct store delivery. A smarter and faster solution is needed. CipherLab’s RS51 series inherited the advantages with enhanced functions to provide smarter and more efficient operation for business’ every-day usage.

Add to Enquiry
Download PDF
Specification
Performance
Operating system Android 8.1 with GMS (Upgradeable to later Android Version) / Android 11 with GMS
CPU Octa-core 1.8GHz
Memory
  • 16GB Flash / 2GB RAM; On request: 32GB Flash / 4GB RAM, 64GB Flash / 4GB RAM
  • 64GB Flash / 4GB RAM
Expansion Micro SD card slot with SDHC (up to 32GB) and SDXC (up to 64GB) support
SIM / SAM 2 SIM slots and 1 SAM slot
Operating power
  • Replaceable and rechargeable 3.8V 4000 mAh Li-ion battery / 3.75V 5300 mAh Li-ion battery
  • Replaceable and rechargeable 3.75V 5300 mAh Li-ion battery
Working hours
  • Minimum 12 hours
  • Minimum 16 hours
Alert 1 tri-color LED,  vibrator, speaker
Interface supported

USB 2.0 OTG and charging contact
Wireless communication
WWAN

GSM / GPRS / EDGE / WCDMA / HSPA+ / LTE

World All-Mode :

  • (2G) GSM: 850/900/1800/1900
  • (3G) CDMA: BC0, BC1, BC10
  • (3G) UMTS/HSPA/HSPA+: B1 (2100), B2 (1900), B4 (1700), B5 (850), B8 (900)
  • (4G) FDD LTE:
    B1 (2100), B2 (1900), Band3 (1800), B4 (1700), B5 (850), B7 (2600), B8 (900), B12 (700), B13 (700), B17 (700), B20 (800), B25 (1900), B26 (850), B28 (700)
  • (4G) TDD-LTE: Band38, Band39, Band40, Band41
WLAN IEEE 802.11 a/b/g/n/ac/e/d/h/i/r/k/v/w
WLAN Security WEP, WPA (PSK, TKIP), WPA2 (AES, PSK), WPA-1X (TKIP,EAP-TLS, PEAP), WPA2-1X (AES, EAP-TLS, PEAP) ,802.1x (EAP-TLS, PEAP) AES-CCMP, WPI-SMS4, WPS2.0, WAPI
WPAN Bluetooth® Class I, V4.2 dual mode, V2.1 with Enhanced Data Rate (EDR)
Bluetooth® profile GAP, SDP, HSP, SPP, GOEP, OPP, HFP, PAN, A2DP, AVRCP, GAVDP, HID, PBAP
GPS Built-in GPS, AGPS, GLONASS, BeiDou, Galileo
Data capture
Barcode scanning 2D imager/Mid-range 2D imager
Camera Autofocus 13 megapixels (F2.0) with user-controllable flash
Physical characteristics
Display 4.7” HD 720 (W) x 1280 (H), Capacitive touch supports bare/wet/gloved fifinger and stylus inputs, DragontrailTM Glass
Interactive Sensor Technology

Light sensor, proximity sensor, accelerometer, e-compass
Keypad Dedicated scan key, 3 programmable keys (volume up and down keys, right trigger key), power key
Voice and Audio VoLTE & HD voice support; Speaker, dual array microphones with echo and noise cancellation
Size (LxWxH) 162 x 80 x 26 mm
Weight 330 g / 365 g
User environment
Operating temperature -20°C to 50°C / -4°F to 122°F
Storage temperature -30°C to 70°C / -22°F to 158°F (without battery)
Humidity (non-condensed) Operating 10% to 90% / Storage 5% to 95%
Impact resistance 1.8 m (6 ft.) multiple drops onto concrete, 6 drops on each side; 1000 tumbles at 1 m; IP65/IP67
Electrostatic discharge ± 15 kV air discharge, ± 8 kV contact discharge
Regulatory compliance CE, Green, NCC, FCC, BC, RoHS, REACH, WEEE, ErP
